IP Test Probe C and D
IP Test Probe C and D are essential tools used to validate the design, electrical safety, and waterproof performance of devices, in compliance with standards such as IEC 60529 and EN 61032. These probes help prevent access to harmful parts inside devices and ensure protection against external elements.
IP Test Probe C Specifications:
- Probe Length: 100 mm
- Probe Diameter: 2.5 mm
- Drop Ball Diameter: 35 mm
- Handle Diameter: 10 mm
- Handle Length: 100 mm
IP Test Probe D Specifications:
- Probe Length: 100 mm
- Probe Diameter: 1.0 mm
- Drop Ball Diameter: 35 mm
- Handle Diameter: 10 mm
- Handle Length: 100 mm
Applicable Standards:
- IEC 60529: This standard defines the protection levels against external factors such as water and dust. The IP codes (IP3, IP4) are determined in this standard, and Test Probes C and D are used for these codes.
- EN 61032: Similar to IEC 60529, this standard outlines the use of test probes to ensure protection against external factors. These probes are designed in compliance with EN 61032.
- UL Standards: UL provides similar requirements for safety testing, usually referencing IEC and EN standards.
- TSE: In Turkey, TSE defines the relevant regulations according to the TS EN 61032 standard.
For detailed information or orders regarding IP Test Probe C and D, please feel free to contact us!
